Technology
- Pivoting C-CAM Gold Dome tweeter and MMP II bass driver.
- High overall efficiency.
- High frequency level adjustment (+/-3 dB).
- Our innovative Tri-Grip fixing system is easier to install than conventional clamping schemes but provides three times the surface area and a better surface seal, maximising bass response and mid-range clarity.
- Magnetic and easily removable steel grille.
- Paint-able surface to blend with the living environment. Additional scrim material is provided for trouble free painting.
- Airtight enclosure design, which protects each precision-engineered driver system against the damaging ingress of dust and dirt.
Specifications:
Frequency Response
75 Hz - 25 kHz
Nominal Impedance
6 Ohms
Sensitivity (1W@1M)
85 dB
Maximum SPL
102.8 dBA
Power Handling (RMS)
50 W
Recommended Amplifier Requirements
20 - 50 W
Crossover Frequency
2.8 kHz @ 12 dB / Octave
Drive Unit Complement
2-Way
5” MMP II cone bass driver
1” C-CAM pivoting Gold Dome tweeter
Adjustment Controls
HF Level Switch (+3dB / 0dB / -3dB)
Overall Diameter (Including Grille)
250 mm (9 13/16 inches)
Overall Depth (Including Grille)
155 mm (6 1/8 inches)
Cut-Out Hole Diameter
212 mm (8 3/8 inches)
Mounting Depth
151 mm (5 15/16 inches)
Fixing Type
3 position Tri-Grip dog leg fixings
Construction Material
Mineral Filled ABS Plastic
(RoHS2 Compliant)
Weight
2.14 kg (4 lb 12 oz)
Connection
Gold plated 'push' type terminals
Pre-Construction Bracket
CB6 Pre-Construction Bracket (Purple)
